OPERATION

MAIN PARTS

FUEL COCK

Fuel valve has two positions:

C : OFF Automatic. If the engine is shut off,

the fuel supply is switched off and the fuel

cannot ﬂ ow from the tank to the carburetor.

A: fuel supply always enabled. The fuel

passes from the tank to the carburetor even

with the engine off.

STARTER

The starter lever 1 is located on the car-

burettor.

To use, pull it out.

HOT START

The hot start 2 is located on the intake

manifold.

To use, pull it out.
